The 16-Outlet C13 C19 US Vertical TCP/IP Sensor Breaker eco Smart Rack PDU is a high-quality power distribution unit designed specifically for data centers and server rooms in the US market. This PDU offers a versatile power distribution solution with a combination of C13 and C19 outlets, suitable for a wide range of devices.With its vertical design, this PDU efficiently utilizes rack space while providing easy access to the 16 power outlets. The C13 outlets are ideal for standard devices, while the C19 outlets are suitable for high-power consumption equipment. This ensures a comprehensive power solution for your data center or server room.The integrated TCP/IP Sensor Breaker Eco Smart technology allows for remote monitoring and control capabilities. With TCP/IP connectivity, you can conveniently access real-time data on power consumption, voltage, current, and temperature from anywhere within your network. This remote monitoring capability simplifies power management tasks, enables proactive maintenance, and ensures optimal performance. -
Equipped with a built-in breaker, this PDU provides excellent protection against power surges, overloads, and short circuits, ensuring the safety of your valuable equipment. Additionally, load balancing capabilities help evenly distribute power among connected devices, maximizing efficiency and preventing power strains.▪ IEC-C19*4(A)+IEC-C13*4(B)+NEMA5-15A*8(C)▪ Available in vertical Zero-U to save space▪ Hydraulic magnetic circuit breaker provides overload protection▪ Processor for flexible control methods via Input/smoke/water / environmental sensor ports and enhanced monitoring via LCD console▪ Host built-in WEB▪ PC management software▪ LAN/Ethernet monitor the total current and voltage or branch current and voltage of the PDU▪ LAN/Ethernet control of PDU power on/off at the total or branch▪ Automatic storage of operation records▪ Set unlimited alarm values of voltage/current▪ Automatic storage of alarm value▪ LAN version automatically switches setting conditions by buzzer alarm or setting external devices (such as alarm devices)▪ Provides API interface for secondary development
16-Outlet C13 C19 US Vertical TCP/IP Sensor Breaker eco Smart Rack Pdu
✓ Efficient Rack Utilization:
✓ Mounting Dimension: 19inch
✓ Mounting Size: 1358mm
✓ Mounting Direction: Vertical
✓ Number of Units: 0U
✓ Width: 60mm
✓ Height: 85mm
✓ Versatile Power Distribution:
✓ Type of Electric Plug Connection: C13/C19/US
✓ Number of Sockets: 16
✓ With TCP/IP: Yes
✓ With Sensor: Yes
✓ With Hydraulic Magnetic Circuit Breaker: Yes
✓ With Mounting Bracket: Yes
✓ Included Accessories: User manual/M6x4 fixing
PRODUCT SPECIFICATIONS
| Feature | Values | ||||||||
| Mounting dimension | 19inch | ||||||||
| Mounting size | 1358mm | ||||||||
| Mounting direction | vertical | ||||||||
| Type of electric plug connection | C13/C19/US | ||||||||
| Number of sockets | 16 | ||||||||
| Number of units | 0U | ||||||||
| Width | 60mm | ||||||||
| Height | 85mm | ||||||||
| With TCP/IP | yes | ||||||||
| With sensor | yes | ||||||||
| With a hydraulic magnetic circuit breaker | yes | ||||||||
| With mounting bracket | yes | ||||||||
| Included accessories | user manual/M6x4 fixing |
