Core and Thread Count in Intel i5 Processors
The Intel Core i5 series is a family of processors known for their balance between performance and cost. The i5-7400T, i5-7400, and i5-7500 all feature four cores and four threads, providing a solid foundation for multitasking and everyday computing tasks. However, starting from the i5-8400, the thread and core count increases to six, offering improved performance in multi-threaded applications and more efficient handling of simultaneous tasks. This six-core, six-thread configuration is consistent across the i5-8400, i5-9400, i5-9400F, i5-9500F, i5-9500, i5-9600, and i5-9600K models.
-
Frequency and Power Consumption in Intel i5 Processors
When it comes to operating frequency, the i5-9600K leads the pack with a base frequency of 3.70 GHz and a maximum turbo frequency of 4.60 GHz. The i5-9600 follows closely with a maximum turbo frequency of 4.60 GHz but a slightly lower base frequency of 3.10 GHz. On the other hand, the i5-7400T operates at a lower base frequency of 2.40 GHz and a maximum turbo frequency of 3.00 GHz, but it stands out in terms of power efficiency. It has a Thermal Design Power (TDP) of just 35 W, significantly lower than the 65 W to 95 W range of the other processors. The i5-9600K, with its higher base and turbo frequencies, has the highest TDP at 95 W.
Intel® Core™ I5-7400T Processors
$99.00 – $228.00
✓ Total cores: 4
✓ Total threads: 4
✓ Maximum turbo frequency: 3.00 GHz
✓ Intel® Turbo Boost Technology 2.0 frequency: 3.00 GHz
✓ Processor base frequency: 2.40 GHz
✓ Cache: 6 MB Intel® Smart Cache
✓ Bus speed: 8 GT/s
✓ Number of QPI links: 0
✓ Thermal Design Power (TDP): 35 W
✓ Configurable TDP-down base frequency: 1.20 GHz
| Specification | I5-7400T | I5-7400 | I5-7500 | I5-8400 | I5-9400 | I5-9400F | I5-9500F | I5-9500 | I5-9600 | I5-9600K |
|---|---|---|---|---|---|---|---|---|---|---|
| Cores | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
| Threads | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
| Base Frequency | 2.40 GHz | 3.00 GHz | 3.40 GHz | 2.80 GHz | 2.90 GHz | 2.90 GHz | 3.00 GHz | 3.00 GHz | 3.10 GHz | 3.70 GHz |
| Max Turbo Frequency | 3.00 GHz | 3.50 GHz | 3.80 GHz | 4.00 GHz | 4.10 GHz | 4.10 GHz | 4.40 GHz | 4.40 GHz | 4.60 GHz | 4.60 GHz |
| Cache | 6 MB | 6 MB | 6 MB | 9 MB | 9 MB | 9 MB | 9 MB | 9 MB | 9 MB | 9 MB |
| Bus Speed | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s | 8 GT/s |
| TDP | 35 W | 65 W | 65 W | 65 W | 65 W | 65 W | 65 W | 65 W | 65 W | 95 W |
| Configurable TDP-down Base Frequency | 1.20 GHz | – | – | – | – | – | – | – | – | – |
